70
Type 8692, 8693
english
Start-up, operation
position controller Type 8692
Example of a programmed characteristic
Valve stroke [&]
(POS)
Unit signal [%]
(CMD)
10
20
30
40
50
60
70
80
90
100
10 20 30 40 50 60 70 80 90 100
0
4 ... 20 mA
0 ... 20 mA
0 ... 10 V
0 ... 5 V
Fig. 14: Example of a programmed characteristic
In the Appendix "Table of position controllers" there is a table in which you can enter your settings for the freely pro-
grammable characteristic.
