BUSKRO BK730-2 - Page 101

Appendix A Assembly Drawings Page A-22
Table A-19: Brush Pivot Assembly (9101112A)
Item Part Number Quantity Description Reference
1 404520 2 Screw, BHCS, 10-32 UNF x 3/8"
2 436300 1 Spring Pin, 3/16" Dia. X 1 3/4" Long
3 9101116A 1 Brush Assembly
4 9101626 1 Brush Pivot Shaft
Figure A-20: Brush Pivot Assembly (9101112A)
Buskro Ltd. BK730-2 Tabber
