Chapter 1 General Information Page 1-6
1.4 Tabber/Labeler Head Specifications
Table 1-2: Tabber/Labeler Head system specifications
Tab Specifications
Number of Tabs 1, 2 or 3
Tab Roll Size Up to 50,000 – 3/4” (paper)
Tab Core Diameter 3.00” 76.2 mm
Tab Spool Size 19.75” 502 mm
Tab Length 1/2” to 5.0” 12.7 to 178 mm
Tab Width Up to 3” (5” with the Wide Label Head) 76mm
Tab Style Circle, square, rectangle, stamps
Tab Type Clear (c/w engineered backer), Paper, Translucent
Tab Placement Front, back or flat tab (gate fold)
Physical
Length
c/w Unwind & rewind spools
32.2” 818 mm
Height
c/w Unwind & rewind spools
37.3” 947 mm
Overall Width 14.1” 330 mm
Weight (Head)
72 lbs 32.6 kg
Software Controls
Product Sensor Selection Selection of Front or Back Product Sensor
Tab Sensor Positioning Set distance between product and peel point sensor
Product Counter Resetting Reset product counter
Software Version Display software version
Factory Reset Reset all setting to factory default
Life Count Display Display the total production to date (can not be reset)
System Test Test all system components for malfunction
Tab Spacing Selection of automatic or manual tab spacing
Number of Tabs Select amount of tab per product
Tab Position Entries Set the distance between tabs on a product
Tab Pitch setting Set tab pitch automatically or manually
Type of Tab setting Set opaque or clear type tab
Peel Point Sensor Sensitivity Adjusts the peel point sensor gain
Material Size Error Fault signal when unexpected product length is detected
Imperial / Metric Unit Display Displays all units in either imperial or metric units
Mechanical Controls
Head Position Slide head on extrusion rail c/w locking lever
Peel Point ⇑ ⇓ Adjustment
Adjustable for materials up to 1 ½” thick
Peel Point Lateral Adjustment Adjustment for different tab width up to 3”
Despool Brake Adjust Adjustable for different production speed
