Table A-35: Tabletop Assembly (325530A)
Item Part Number Quantity Description Reference
1 100530 1 Belt Takeup shaft
2 100531 1 Table Belt Drive Shaft
3 100532 2 Lower Roller Shaft
4 106530 2 Outer Takeup Roller
5 106531 1 Center Belt Takeup Roller
6 106532 4 Pinch Roller
7 106533 2 Outfeed Pinch Roller
8 106534 2 Table Belt Drive Pulley
9 106535 2 Vacuum Belt Drive Pulley
10 110207 1 Gear, NSS1636 x 3/4"
11 116309 1 Pulley, 18LB075 x 3/4" w/o Shoulder
12 116530 2 Pulley, 22XL037 x 5/8"
13 116531 1 Pulley, 12LF050 x 5/8"
14 116532 1 Pulley, 18LB050 x 3/4"
15 120209 1 Timing Belt, 90XL037
16 120317 1 Timing Belt, 187L050
17 120342 1 Timing Belt, 420L075
18 120530 2 Tabber Table Belt (1" x 99")
19 120531 2 Tabber Table Belt (2" x 99")
20 325530 1 Tabber Tabletop
21 330530 2 Takeup Roller Block
22 330531 2 Drive Roller Block
23 330532 2 Lower Roller Block
24 403310 4 Screw, PHMS, 8-32 UNC X 1/4"
25 404030 4 Screw, FHCS, 10-32 UNF x 1/2"
26 404040SS 4 Screw, FHCS, 10-32 UNF x 5/8" SS
27 404510 4 Screw, BHCS, 10-32 UNF x 1/4"
28 404540SS 4 Screw, BHCS, 10-32 UNF x 5/8" SS
29 404807 6 Screw, SHSS, 10-32 UNF x 3/16"
30 404820 4 Screw, SHSS, 10-32 UNF x 3/8"
31 404830 1 Screw, SHSS, 10-32 UNF x 1/2"
32 405820 2 Screw, SHSS, 1/4-20 UNC x 3/8"
33 405830 5 Screw, SHSS, 1/4-20 UNC x 1/2"
34 405850 4 Screw, SHSS, 1/4-20 UNC x 3/4"
35 430250 10 Woodruff Key, #606, 3/16" X 3/4"
36 436300 1 Spring Pin, %%C3/16 x 1 3/4" Long
37 440008 4 Washer, #10 ID
38 500045 4 Bearing, UBR202-10S, 5/8" ID
39 500055 4 Bearing, UBR-204-12S, 3/4" ID
40 706533 2 Upper Photosensor Bracket
41 707532 1 Left Form Plate Guide
42 707533 1 Right Form Plate Guide
43
9101271 2 Nut, M12
Note: Belts 120530 and 120531 are ordered as a belt set (9103545A).
