Chapter 2 BK730-2 Base Page 2-11
S1-6 (RUN) This switch is connected in parallel to the RUN
Enable/Disable switch on the front panel. This switch
enables or suppresses the upstream START signal. The
function would be used for testing, when the operator
wishes to start the machine, without starting the upstream
section of the system.
For machines which have a front panel switch, S1-6
should be open (=enabled) to enable the operation of the
front panel switch, otherwise it should be closed
(=disabled).
JP1 Determines how the board handles a JAM input and the
effect of S1-4. For some applications it is desirable to
suppress the STOP signal from the JAM sensor, but to still
report the condition to the control computer. In this case,
selection 1-2 should be used at jumper location JP1.
If no control computer is connected, either position may
be used, with 1-2 preferred.
1 – 2: Jam signal is ignored by the board, but still passed
on to the control computer.
2 – 3: Jam signal is ignored by the board, and not passed
on to the control computer.
2.2.4 The Speed Control Board (p/n 9102421)
The Speed Control Board (p/n 9102421) is a new option for Buskro systems enabling the
speed of an entire production line to be controlled from a single location regardless of the
number of subsystems involved. It is intended for the integration of systems with two or
more separate pieces of equipment. In order for this feature to work, each individual
subsystem, whether it is a Buskro unit or third party equipment, will require:
the Speed Control Board (p/n 9102421) as shown in
Figure 2-5
A Buskro approved encoder (6000 PPR)
Production speed potentiometer
Buskro Ltd. BK730-2 Tabber
