Appendix A Assembly Drawings Page A-31
Table A-27: Peel Point Assembly (9101264A)
Item Part Number Quantity Description Reference
1 401010 4 Screw, FHCS, 4-40 UNC x 1/4"
2 606014 1 Cable, #22-4, Shielded, (24" Long)
3 9100724 1 Plug, Preh, Locking, 3 Pin
4 9101072 1 AIGaAs Infrared Emitting Diode
5 9101074A 1 Peel Point
6 9101104 2 Peel Point Top Cover
7 9101264 1 Sidelooker Phototransistor
8 9101669 4 Shrink Wrap, 1/16" I.D., 125 C, 500V (1" Long)
9 9101670 2 Shrink Wrap, 1/4" I.D., 125 C, 500V (3" Long)
10 9101671 1 Shrink Wrap, 1/2" I.D., 125 C, 500V (3" Long)
11 9103573 2 Plate, Peel Point Notch
12 9103578 1 Label, Peel Point Cable Warning
13 9103598 2 Tape, Double-Sided Foam
14 9103678 1 Label, Peel Point S/N
Buskro Ltd. BK730-2 Tabber
