Appendix A Assembly Drawings Page A-59
Buskro Ltd. BK730-2 Tabber
Table A-48: Cable, Downstream to BCB (9104144A)
Item Part Number Quantity Description Reference
1 606016 1 Cable, #22-15 Shielded, 68" Sleeved Length, 75" Total
2 609003 2 Shrink Wrap, 3/8" I.D., 1"
3 614113 1 Cable Clamp
4 9100197 1 14-Pin Weidmuller
5 9100785 14 Contact, Female, 24-20 AWG, Size 20 DF
6 9102054 1 Receptacle, Female, 23-57
7 9103468 14 Ferrule, #22 AWG, Turquoise
Figure A-50: Cable, Downstream to BCB (9104144A)
6
1
5
14
3
1
2
2
1
1
4
1
7
14
1
14
3.7" 11
3.9"
4.1"
3.5"
14
13
12
2.7"
3.3"
3.1"
2.9"
8
10
9
7
Red
White
Green
Black
Red/Black
Blue
Orange
White/Black
9100197
9102054 Pin
-1-6
Colour
-
Remote start FROM downstream equipment
Remote start FROM downstream equipment
Remote stop FROM downstream equipment
Remote stop FROM downstream equipment
Remote start To Downstream equipment
Remote stop To Downstream equipment
Remote start To Downstream equipment
Remote stop To Downstream equipment
Description
Not Connected
Follow+Signal FROM downstream equipment
Follow-Signal FROM downstream equipment
2.1"
1.9"
Red/White19
20 Green/White
- Not Connected-
15-18
Not Connected- 21-28 -
Ground For Heater Table Control
Switched +12VDC for Heater Table Control
Not Connected
Master -Signal from Downstream equipment
Master +Signal from Downstream equipment
2.5"
-
2.3"
Orange/Black
Green Black
35
34
Black/White
Blue/Black
31-33
30
29
-
36-57
Not Connected-
1.7"
1.5"
-
Pin
3
2
1
4
8
5
6
7
-
13
14
-
-
9
-
10
11
12
-
Unsleeved
Wire Length
to Connector
VIEW A
VIEW A
1
4
10
17
25
33
41
48
54
57
55
5
11
18
26
34
42
49
REFER TO TABLE FOR UNSLEEVED
LENGTH OF EACH WIRE
