Chapter 4 User Interface Page 4-2
4.2 Keypad Setup Menu
The “Setup” button on the keypad permits the configuration of the head. The sub-
commands under Setup are as follows:
• Front or Back Product Sensor Selection
• Product Sensor Position Setting
• Reset production count
• Display software version
• Reset to default factory settings
• Life count
• Form Size Error selection
• Display metric or imperial values
4.2.1 Front or Back Product Sensor Selection
The Product sensor detects the presence of a product to be labeled. This setting is mainly
used on the BK730-2 which includes both a front and back through-beam sensor and
requires the ability to switch between them. For a standalone Labeler, only the FWD
setting is used. In order to switch between sensors, follow the below instructions:
1. Put the head into “OFFLINE” mode by pressing the <Online> key. The keypad
will display an “OFFLINE” message.
2. Press the <Setup> button. The display should read “PRODUCT SENSOR:
FWD” or “PRODUCT SENSOR: BAK”. If not, scroll through the menu by
pressing the Up or Down arrow until the Product Sensor option is displayed.
3. Press <-> or <+> in order to select FWD or BAK. When your selection is made,
press <Online>.
Note: If an incorrect product sensor has been chosen, then the system will not detect
the conveyed products and labels will not be dispensed from the Labeling head.
Buskro Ltd. BK730-2 Tabber
