Appendix A Assembly Drawings Page A-56
Buskro Ltd. BK730-2 Tabber
Table A-46: Base Cabinet Assembly (9104015A)
Item Part Number Quantity Description Reference
1 343010 4 Base Mounting Foot
2 343015 4 Base Mounting Leg
3 343016 4 Jam Nut, 3/4-10 UNC
4 402320 16 Screw, PHMS, 6-32 UNC x 3/8"
5 402510 2 Screw, BHCS, 6-32 UNC x 1/4"
6 404510 17 Screw, BHCS, 10-32 UNF x 1/4"
7 405230 4 Screw, SHCS, 1/4-20 UNC x 1/2"
8 420010 16 Nut, 1/4-20 UNC
9 420010SS 4 Nut, 1/4-20 UNC SS
10 439007 3 Lockwasher, 1/4", External Tooth
11 439010 16 Lockwasher, 1/4" I.D.
12 440010 16 Washer, 1/4" I.D.
13 440510 4 Rubber Washer, 1/4" I.D.
14 606531A 1 Cable, Conveyor Receptacle
15 614109 7 Pin, Power Contact
16 614127 1 Receptacle, 23-7 AMP
17 615102 9 Tie Mount
18 615141 9 Lashing Tie
19 717530 4 Door Catch
20 803530 4 Caster, Swivel, 4 in
21 9102068 16 Bolt, Carriage, 1/4-20 UNC, 3/4" LG.
22 9102930 1 Cord, 15A/125VAC, 2.5m, N.A., IEC
23 9103968A 1 Cabinet, Base Assembly, BK730A-2
24 9104143A 1 Cable, Rear Panel, Upstream to BCB Page A-58
25 9104144A 1 Cable, Downstream to BCB Page A-59
26 9104451A 1 Cable, #21, Power from IEC to Front Panel Page A-60
To Next Page
