Appendix A Assembly Drawings Page A-2
Table A-2: Tabber Skidbar Assembly (330740A)
Item Part Number Quantity Description Reference
1 100021H 2 Front Skidbar Shaft
2 100026 2 Hollow Skidbar Shaft
3 203003 2 Skidbar Arm
4 209003 2 Spring, 1/2", Extension
5 330018H 2 Skidbar Holder Block
6 330302 2 Skidbar Bracket
7 343006 2 Skidbar Holder Clamp
8 403250 2 Screw, SHCS, 8-32 UNC x 3/4"
9 403260 2 Screw, SHCS, 8-32 UNC x 7/8"
10 404030 8 Screw, FHCS, 10-32 UNF x 1/2"
11 404040 4 Screw, FHCS, 10-32 UNF x 5/8"
12 404240 8 Screw, SHCS, 10-32 UNF x 5/8"
13 404570 2 Screw, BHCS, 10-32 UNF x 1"
14 404820 4 Screw, SHSS, 10-32 UNF x 3/8"
15 405520 2 Screw, BHCS, 1/4-20 UNC x 3/8"
16 405530 2 Screw, BHCS, 1/4-20 UNC x 1/2"
17 406530 2 Screw, BHCS, 5/16-18 UNC x 1/2"
18 436030 2 Spring Pin, 1/8" Dia. x 1/2"
19 436050 2 Spring Pin, 1/8" Dia. x 3/4"
20 438171 4 Thumbscrew, 10-32 UNF x 3/8"
21 440020 1 Washer, 3/8" I.D.
22 500211 12 Skidbar Ballbearing, 3/4" O.D.
23 505003 2 Bushing, 3/16" I.D. X 5/16 O.D. x 1/2 LG.
24 505004 2 Bushing, 3/4" I.D. X 7/8 O.D. x 1/2 LG.
25 9100485 2 Lever Handle, 1/4-20 UNC x 1 1/2"
26 9101059 4 Support Block, Tabber Rail
27 9101064 1 Tabber Mounting Rail
28 9101126 1 Double T nut
29 9101243 1 Skidbar Body
30 9101246 2 Ball Retention Spring, 13.47"
31 9101248 6 Bearing Pad, Tabber Head Mount
32 9101249 1 Rail Mounting Block
33 9101269 1 Handle, Racheting, 15 Series
34 9101398 1 Economy T-slot Stud, 5/16-18 UNC x 1"
35 9101492 1 Mounting Slide, AL
36 9101622 1 Mounting Bracket, Aligning Rail
37 9101623 1 Mounting Block, Slide Rail
38 9101624 1 End Caps (15 Series)
Buskro Ltd. BK730-2 Tabber
