Appendix A Assembly Drawings Page A-38
Buskro Ltd. BK730-2 Tabber
Table A-33: Base, BK730-2, 115 VAC (9103970A)
Item Part Number Quantity Description Reference
1 116533 1 Pulley, 12LF050 X R6
2 120323 1 Timing Belt, 225L050
3 212430 1 Right Side Guide
4 212431 1 Left Side Guide
5 212735A 1 Upper Transport Assembly (BK730) Page A-41
6 325530A 1 Tabletop Assembly Page A-43
7 330730A 1 Tabber Base Mechanical Assembly Page A-45
8 404030 11 Screw, FHCS, 10-32 UNF x 1/2"
9 404520 8 Screw, BHCS, 10-32 UNF x 3/8"
10 407280 10 Screw, SHCS, 3/8-16 UNC x 1 1/2"
11 407675 3 Screw, HHMS, 3/8-16 UNC x 1 1/4"
12 416175 1 Shoulder Bolt, 3/8" x 1 1/4", (5/16-18)
13 420008 11 Nut, 10-32 UNF
14 439009 11 Lockwasher, No. 10
15 439020 13 Lockwasher, 3/8" I.D.
16 440008 11 Washer, #10 ID
17 440020 13 Washer, 3/8" ID
18 530707A 1 Tabber Motor Assembly Page A-50
19 700534 1 Right Upper Cabinet Cover
20 700535 1 Left Upper Cabinet Cover
21 700542 1 Rear Panel Access Door
22 700743A 1 Connector Plate Assembly, BK730 Page A-52
23 9101640 2 Handle, Panel Snap Style
24 9102380 1 Board, Base Control
25 9103686 1 Strain Relief, 1/2" NPT, 0.28-0.47" OD, Black Nylon
26 9103789 4 Latch, Quarter turn, 51 mm
27 9103792 2 Door, Base Cabinet
28 9103882A 1 Front Door Assembly, BK730A-2 Page A-53
29 9103883A 1 Front Panel Assembly, Tabber Version 2 Page A-54
30 9103884 1 Panel, Rear, BK730A-2
31 9104015A 1 Base Cabinet Assembly, BK730A-2 Page A-57
32 9104173A 1 Terminal Block Assembly, Rear Panel, BK730A-2 Page A-61
