Table 1-3: Tabber/Labeler Base and Head Dimensions
Symbol Description Dimensions
WB Overall Base Width 28.00” 710 mm
WR Front Lateral Extension 6.00” 152 mm
WL Back Lateral Extension 6.50” 165 mm
OL Overall Length 44.18” 1122 mm
OH Overall Height 71.90” 1826 mm
OW1 Overall Tabber Head Width 14.11” 358 mm
OL1 Overall Tabber Head Length 32.15” 816 mm
X1 Leveling Foot Length 46.69” 1185 mm
X2 Right Head Mount 26.00” 660 mm
X3 Left Head Mount 17.39” 711 mm
X4 Despool Center Distance 9.39” 238 mm
X5 Take-up Spool Center Distance 19.64” 499 mm
Y1 Tabletop Height 34.30” - 36.50” 869 mm - 927mm
Y2 Tabber Head Support Height 37.90” 962 mm
Y3 Take-up Spool Height 11.00” 279 mm
Y4 Despool Height 24.00” 609 mm
Z1 Leveling Foot Width 24.00” 609 mm
Z2 Upper Transport Width 24.53” 623 mm
Z3 Front Face Width 8.31” 211 mm
D1 Despool Diameter 19.75” 502 mm
D2 Take-up Spool Diameter 13.00” 330 mm
