BUSKRO BK730-2 - Page 144

Appendix B Electrical Drawings Page B-3
Figure B-3: BK730-2 Cable Reference Chart – Page 1 of 5
AWG Colour P/N
9103433 - single wire
9103434 - dual wire
16 Red 9103435
9103539 - single wire
9103724 - dual wire
20 Orange 9103538
22 Turquoise 9103468
24 Light Blue 9103540
Ferrules: Wire Size vs. Colour
Blue14
18 White
Cable # Purpose Buskro P/N Cable P/N Wire Gauge Length [in] Wire Colours
1
Line, neutral, ground from rear terminal block assembly to power
connector on Tabber Connector Plate
(p
/n 700743A
)
.
700743C1 606033 16 AWG GN, WH, BK
2
Stop output from Head to conveyor stop input on Base Control Board
J7.
700743C2 606531 22 AWG BK, WH
3
Encoder cable splitting encoder signal to Base Control Board and
Tabber Head.
700743C3 606012 22 AWG WH, GN, RD, BK
4A Connects front
p
roduct sensor emitter to Tabber Connector Plate. BK, WH
4B Connects front
p
roduct sensor receiver to Tabber Connector Plate. BK, WH
4C Connects back
p
roduct sensor emitter to Tabber Connector Plate. BK, WH
4D Connects back product sensor receiver to Tabber Connector Plate. BK, WH
5
Jam cable from rear terminal block assembly to Tabber Connector
Plate.
700743C5 606531 22 AWG BK, WH
6
Cable from rear terminal block assembly to Upper Transport Safety
cover sensor
(p
/n 9101557A
)
9104437A 606531 22 AWG BK, WH
7
Cable from rear Terminal block assembly to Jam Switch Assembly
(p
/n 603520A
)
.
9104438A 606531 22 AWG BK, WH
8
Cable from rear terminal block assembly taking signal from Jam
Switch Assembl
y
to Jam in
p
ut on Base Control Board J10.
9104439A 606531 22 AWG BK, WH
9
Cable from 115 VAC relay normally closed (N/C) contacts to the
Conve
y
or Sto
p
in
p
ut on the Base Control Board J7.
9104440A 606531 22 AWG BK, WH
10
Cable from downstream connection at J1 of Base Control Board to
Downstream Connector on the base cabinet.
9104144A 22 AWG
WH/GN, WH/RD, BK/WH, BU/BK, OG/BK, GN/BK,
RD/BK, WH/BK, BU, OG, GN, RD, WH, BK
11
Upstream cable from J2 on Base Control Board to upstream
connector on the Base Cabinet.
9104143A 22 AWG
WH/GN, WH/RD, BK/WH, BU/BK, OG/BK, GN/BK,
RD/BK, WH/BK, BU, OG, GN, RD, WH, BK
12
Cable from Speed Control J3 on Base Control Board and 12 VDC J6
to 12 VDC
p
ower su
pp
l
y
and s
p
eed control in front
p
anel.
9104443A 606018 22 AWG
WH, BK, GY, VIO, BU, GN, YEL, OG, RD, BN
13 Cable from J5 on Base Control Board to RUN rela
y
in front
p
anel. 9104444A 606012 22 AWG WH, GN, RD, BK
14
Cable from J8 on Base Control Board to Front Panel controls for
Start, Sto
p
, Jo
g
/Run, and Feed Enable.
9104445A 9104140 22 AWG BN, GN, RD, WH, BK
16
Cable to split encoder signal to go to Base Control Board J10 and to
Head via cable #3.
9104447A 606012 22 AWG WH, GN, RD, BK
17 Cable from Encoder Assembl
y
to cable #16. WH, WH/BN, RD, BK
18
Power connection from Front Panel Assembly to Rear Terminal Block
Assembl
y
.
9104449A 606033 16 AWG GN, WH, BK
19 Jam Switch Assembl
y
cable to cable #7. 603520
A
606531 22 AWG BK, WH
20 Power to Motor 9104450A 606034 16 AWG GN, WH, BK
21
Cable connecting L, N, G from IEC connector to front panel terminal
block assembl
y
.
9104451A 606034 14 AWG GN, WH, BK
22
Connects +12VDC for master speed control module and master
s
p
eed si
g
nal to the s
p
eed control board.
9104452A 606012 22 AWG WH, GN, RD, BK
23
Connects +12VDC and ground from power supply to Speed Control
Board J1.
9104453A 606532 22 AWG BK, RD
24
Cable connecting front panel speed production potentiometer to J2 on
the S
p
eed Control Board.
9104454A 606012 22 AWG BK, WH, RD
25
Cable from Front Panel Base Power and Head Switch to L, N, G on
front terminal block assembl
y
.
9104455A 606530 18 AWG GN, WH, BK, BN, BU
26 Control cable to Dart Board 9104456A 606012 22 AWG BK, WH, RD
27 Power to Dart Control Board 9104457A 606035 18 AWG BK, WH
28 Control cable to S
p
eed Control Board 9104458A 606012 22 AWG BK, WH, RD
29 Power cable from +12VDC su
pp
l
y
to L, N, G 9104459A 606043 18 AWG BK, WH, RD
30 Conveyor Extension Cable 606531A 14 AWG BK, WH, GN, RD, BU, WH/BK
700743C4 22 AWG606531
