BUSKRO BK730-2 - Page 154

Appendix B Electrical Drawings Page B-13
Figure B-13: BK731-2 Tabber Head Wiring - Page 6 of 6
2-PHASE DRIVER
+5 VDC
RED
BLUE
GREEN
BLACK
LINE
MOTOR
NEUTRAL
J4
J3
To Terminal Blocks
Page 2
To Tab Step Motor
Page 1
RD
BU
GN
BK
GN
WH
BK
(GROUND)
(GROUND)
100/115 ~
To Tabber
Interface Board:
Page 4
BK
WH
TABSET
Buskro Ltd. BK730-2 Tabber
