Chapter 4 User Interface Page 4-12
In order to set the label pitch automatically perform the following:
1. If the keypad does not say “OFFLINE”, press the <Online> key.
2. Press the <Labels> button. The display should read “AUTO CONFIG
<ENTER>”. If not, press the Down arrow key until it does.
3. Place a product underneath the Peel Point Assembly. Now press <ENTER>. The
BK731-2 should release two labels during its configuration procedure.
4. Repeat step 3.
5. Press <Online> to exit the Labels menu.
In order to set the label pitch manually:
1. If the keypad does not say “OFFLINE”, press the <Online> key.
2. Press the <Labels> button.
3. Press the Down arrow key until the display reads “PITCH: #.###”.
4. Using the keypad, enter in the label pitch and press <Enter> (
5. Figure 4-3).
6. Press <Online> to exit the Labels menu.
Note: It is recommended that the automatic label pitch setting be used.
If the Label Pitch entry is not accurately set, the result will be that each successive
label applied will drift incrementally on successive products. That is, the first label
may be applied at 1” from the lead edge, with the second applied at 1.05”, the
third one at 1.1” and so on.
The label sensor gain will also need adjustment for accurate label placement
when the manual label pitch function is used.
Buskro Ltd. BK730-2 Tabber
