Modulation
Following tables list modulation supported during L2 and L3 throughput:
Table 3: Modulation and coding rate for CB1
MCS Modulation Coding Rate L2 Throughput (Mb/s)
DMG-CB1 (2.16 GHz
Channel)
2 π/2 BPSK 1/2 572
3 π/2 BPSK 5/8 800
4 π/2 BPSK 3/4 914
6 π/2 QPSK 1/2 1256
7 π/2 QPSK 5/8 1600
8 π/2 QPSK 3/4 1828
9 π/2 QPSK 13/16 1942
10 π/2 16QAM 1/2 2400
11 π/2 16QAM 5/8 3200
12 π/2 16QAM 3/4 3656
Table 4: Modulation and coding rate for CB2
MCS Modulation Coding Rate L2 Throughput (Mb/s)
EDMG-CB2 (4.32 GHz
Channel)
2 π/2 BPSK 1/2 1244
3 π/2 BPSK 5/8 1524
4 π/2 BPSK 3/4 1750
5 π/2 BPSK 13/16 1792
7 π/2 QPSK 1/2 2280
8 π/2 QPSK 5/8 2740
9 π/2 QPSK 3/4 3480
10 π/2 QPSK 13/16 3800
11 π/2 QPSK 7/8 4260
12 π/2 16QAM 1/2 5000
13 π/2 16QAM 5/8 5420
