Installation 134
Figure 126:
Connecting the output side of AC/DC PSU
Install the PSU
Install one of the following types of PSU:
l Installing the 60W DC power injector
l Installing the AC/DC PSU
l Installing 15W or 30W power injector
Table 36: Details of PoE injector to be used for cnWave 60 GHz products
Product Without AUX POE Enabled With AUx
POE
enabled
V1000 15W Not
applicable
V2000 30W 60W
V3000 60W 60W
V5000 60W 100W
Warning
Always use an appropriately rated and approved AC supply cord-set in accordance with the
regulations of the country of use.
Attention
As the 60W DC power injector and V1000 power injector are not waterproof, locate it away
from sources of moisture, either in the equipment building or in a ventilated moisture-proof
enclosure. Do not locate the PSU in a position where it may exceed its temperature rating.
