System Hardware 43
Bracket Radio nodes Cambium Part Number
Pole mount bracket V5000 C000000L137A
Precision bracket V3000 C000000L125A
Radio accessories
Telescope mounting kit for precision brackets
The Precision bracket and an alignment telescope provide the most accurate option for aligning the radio
during installation. The telescope is temporarily mounted on the bracket using the telescope mounting kit
for precision brackets.
The telescope mounting kit consists of a mounting plate, a knurled screw, and two rubber O-rings.
Order the telescope mounting kit from Cambium Networks.
Figure 25:
Telescope mounting kit
Order a suitable telescope from a specialist supplier specifying the following details:
Right angle, erecting, 9x50 mm alignment scope with 5° field of view
