System Hardware 49
Radio specifications
The 60 GHz cnWave Radios conform to the specifications listed in Radio node specifications.
Table 15: Radio node specifications
Category Specification
Dimensions V1000 Client Node 169 mm × 100 mm × 54 mm (6.6 in × 3.9 in ×
2.1 in)
V2000 Client Node 250 mm x 166 mm x 220 mm (9.8 in x 6.5 in x
8.6 in)
V3000 Client Node (44.5 dBi)
V3000 Client Node (40.5 dBi)
421 mm x 347 mm x 349 mm (16.5 in x 13.6 in
x 13.7 in)
343 mm x 198 mm x 251 mm (13.5 in x 7.7 in x
9.8 in)
V5000 Distribution Node 280 mm × 186 mm × 103 mm (11.0 in × 7.3 in ×
4.0 in)
Weight V1000 Client Node 0.46 kg (1.01 lbs)
V2000 Client Node 1.9 kg (4.18 lbs)
V3000 Client Node (44.5 dBi) 4.17 kg (9.1 lbs) including big antenna dish
6.12 kg (13.4 lbs) = radio with dish + precision
bracket
V3000 Client Node (40.5 dBi) 3.2 kg (7.05 lbs) including small antenna dish
5.15 kg (11.3 lbs) = radio with dish + precision
bracket
V5000 Distribution Node 3.12 kg (6.8 lbs) including antenna dish
3.76 kg (8.2 lbs) = radio with dish + universal
pole bracket
Temperature -40°C (-40°F) to +60°C (140°F)
Wind survival 200 kph (124 mph) maximum
Humidity 100% condensing
Liquid and particle
ingress
IP66, IP67
Power consumption V1000 Client Node 10 W
V2000 Client Node 18 W without PoE and 48 W with POE
enabled
V3000 Client Node 30 W, up to 60 W with PoE Out enabled
V5000 Distribution Node 35 W, up to 65 W with PoE Out enabled
