System Hardware 36
Figure 15:
V5000 Distribution Node front and rear views
V5000 Part numbers
Order the V5000 Distribution Node (DN) from Cambium Networks (as shown in below table). The V5000
DN is supplied without a mounting bracket or power supply.
Table 8: V5000 DN part numbers
Cambium description Cambium part number
60GHz cnWave V5000 DN C600500A004A
60GHz cnWave V5000 Distribution Node - Israel Only C600500A005A
Radio mounting brackets
V1000 Wall and pole mount
The V1000 CN is supplied with a mounting plate and a band clamp. The mounting plate can be used for
mounting the V1000 on a wall, or it can be used with the supplied band clamp to mount the V1000 on a
pole with a diameter in the range of 25 mm to 70 mm (1 inch to 2.75 inches). Note that the larger
diameters can be accommodated with the customer supplied clamps.
