System Hardware 57
Table 19: PoE, 60W, 56V, 10 GbE DC injector (C000000L141A)
Category Specification
Dimensions 140 mm (5.5 in) x 53 mm (2.08 in) x 35 mm (1.37 in)
Weight 0.24 Kg (0.5 lbs)
Temperature 0°C (32°F) to +50°C (140°F)
Humidity 10% to 95 % non-condensing
AC Input 90-264 V AC, 47-63 Hz
DC Output voltage 56V
DC Output current 1.07 A
Efficiency Better than 88% at full load
Over Current Protection Hiccup mode, recovers automatically after the fault condition is removed
Hold up time At least 10 milliseconds
RJ45 POE Port 1,2,7,8 ------------- DC V-
3,4,5,6 ------------- DC V+
