Contents 7
AC Supply 94
Powering down before servicing 94
Primary disconnect device 95
External cables 95
Drop cable tester 95
RF Exposure near the antenna 95
Minimum separation distances 95
Grounding and lightning protection requirements 95
Grounding cable installation methods 95
Siting radios 96
60 GHz cnWave radios and mounting bracket options 96
Installing the cnWave radio nodes 96
ODU Interface with LPU on the pole 101
Attach ground cables to the radio 105
Mounting the ODU 105
Connect to the PSU port of the radio 128
Using power over Ethernet (PoE) 128
Using AC/DC PSU 132
Install the PSU 134
Installing the 60W DC power injector 135
Installing the AC/DC PSU 137
Installing 15W or 30W power injector 138
Connecting to the SFP+ optical module or SFP+ to the copper module to ODU 139
Removing the cable and SFP module 145
Configuring 60 GHz cnWave™ 147
Nodes deployment 147
Connecting to the unit 147
Configuring the management PC 147
Connecting to the PC and powering up 149
Using the web interface 149
