COPIER (Service mode for printer) > FUNCTION (Operation / inspection mode) > SPLMAN
LEFT-MPT Adj left edg mar: pickup from MP Tray
Detail As the value is changed by 1, the margin on the left edge of paper is changed by 0.1 mm.
+: Left edge margin becomes larger. (An image moves to the right.)
-: Left edge margin becomes smaller. (An image moves to the left.)
Use Case
When adjust the left edge margin at the time of pickup from the Multi-purpose Tray.
Adj/Set/Operate Method
Enter the setting value, and then press OK or Apply key.
Display/Adj/Set Range
50 to 150
Unit
0.1 mm
Default Value
91
LEFT-DUP-MPT Adj left edg mar 2nd of 2-sided: MP Tray
Detail As the value is changed by 1, the margin on the left edge of paper is changed by 0.1 mm.
+: Left edge margin becomes larger. (An image moves to the right.)
-: Left edge margin becomes smaller. (An image moves to the left.)
Use Case
When adjusting the left edge margin of the 2nd side of the 2-sided printing at the time of pickup
from the Multi-purpose Tray.
Adj/Set/Operate Method
Enter the setting value, and then press OK or Apply key.
Display/Adj/Set Range
50 to 150
Unit
0.1 mm
Default Value
92
TOP-CST Adjust leading edge margin
Detail As the value is changed by 1, the margin on the leading edge of paper is changed by 0.1 mm.
+: Leading edge margin becomes larger. (An image moves to the trailing edge.)
-: Leading edge margin becomes smaller. (An image moves to the leading edge.)
Use Case
When adjusting the leading edge margin at the time of pickup from the Pickup Tray.
Adj/Set/Operate Method
Enter the setting value, and then press OK or Apply key.
Display/Adj/Set Range
50 to 150
Unit
0.1 mm
Default Value
100
TOP-DUP-CST Adj lead edg mar: 2nd of 2-sided
Detail As the value is changed by 1, the margin on the leading edge of paper is changed by 0.1 mm.
+: Leading edge margin becomes larger. (An image moves to the trailing edge.)
-: Leading edge margin becomes smaller. (An image moves to the leading edge.)
Use Case
When adjusting the leading edge margin of the 2nd side of the 2-sided printing at the time of pickup
from the Pickup Tray.
Adj/Set/Operate Method
Enter the setting value, and then press OK or Apply key.
Display/Adj/Set Range
50 to 150
Unit
0.1 mm
Default Value
100
LEFT-CST Adjust left edge margin
Detail As the value is changed by 1, the margin on the left edge of paper is changed by 0.1 mm.
+: Left edge margin becomes larger. (An image moves to the right.)
-: Left edge margin becomes smaller. (An image moves to the left.)
Use Case
When adjusting the left edge registration margin at the time of pickup from the Pickup Tray.
Adj/Set/Operate Method
Enter the setting value, and then press OK or Apply key.
Display/Adj/Set Range
50 to 150
Unit
0.1 mm
Default Value
91
