Countermeasure against shaving on the shaft of the upper
registration roller
[Symptom/Question]
Shavings [a] of the shaft may be attached around the both ends of the upper registration roller [1] in the machine earlier than the
following countermeasure cut-in serial numbers in factory.
[Cause]
After some endurance time has elapsed, the outer periphery of the bearing of upper registration roller and the inner periphery of
the roller scuff and shave each other, and this leads to the above mentioned symptom.
[Remedy/Answer]
When the aforementioned symptom has occurred, prepare and replace with the new type upper registration roller (FM1-F405-010)
referring to the "Replacement Manual for Durability Enhancement Parts". When to replace, first wipe off the shavings before
performing the work.
[Service Parts]
No. Part Number Description Q'ty Fig.No.
1
Old FM1-F405-000 ROLLER, REGISTRATION, UPPER 1 -> 0
320
New FM1-F405-010 ROLLER, REGISTRATION, UPPER 0 -> 1
[Countermeasure cut-in serial numbers in factory]
Model Serial No.
imagePRESS C10000VP Series ME US WBC10777
imagePRESS C10000VP Series ME CN WBD00550
imagePRESS C10000VP Series ME EUO WEJ10827
247
