Non-glossy lines with a width of 7 mm due to the life of fixing belt
[Symptom]
When a high-density image is output, non-glossy lines with a width of 7 mm wide [a] may occur.
The arrow indicates the feeding direction of media.
[Cause]
Wrinkles appear on the well-worn fixing belt [1] and it results in the symptom.
The green arrows indicate the paper delivery paths.
[Service work]
Prepare new fixing belt (FL0-0358-000) to replace with reference to Service Manual.
28
