PREFACE 13
imagePRESS Server components
The terms “replace” and “replacing” are used throughout this guide to mean the reinstallation
of existing components. Install new components only when necessary.
NOTE: Replacement parts and specifications are subject to change. When ordering
replacement parts, refer to the current parts list maintained by your authorized
service/support center. Install the correct parts as directed by your service/support center.
The term “Control Panel” refers to the area on the front of the imagePRESS Server, including
the green/red activity light, the display window (LCD—liquid crystal display), and the
buttons to the left and right of the display window.
The term “LCD” refers to the display window of the imagePRESS Server Control Panel.
The term “monitor” refers to the optional imagePRESS Server flat panel monitor.
The term “DVD drive” (Digital Versatile Disk drive) refers to the imagePRESS Server
DVD drive.
The term “system software” refers to the following software installed on the
imagePRESS Server hard disk drive (HDD):
• Windows XP Pro for Embedded Systems operating system and imagePRESS Server
Software (System Software DVD 1)
• User Software (System Software DVD 2)
For other terms used to identify components of the imagePRESS Server, see the reference key
in Figure 13 on page 47.
Connectors and components labeled “not used”
Connectors and components labeled “not used” are disabled or are not used in the standard
imagePRESS Server configuration.
Document conventions
References to imagePRESS Server user documentation, such as Configuration and Setup, are
displayed in italics. The user documentation files are installed from the User Documentation
CD.
NOTE: The NOTE format highlights important messages and additional information.
The WARNING format indicates a potentially hazardous situation which, if instructions are
not followed, could result in death or serious injury. To use the imagePRESS Server safely,
always pay attention to these WARNINGs.
The CAUTION format indicates a caution concerning operations which, if not performed
correctly, may lead to injury. To use the imagePRESS Server safely, always pay attention to
these CAUTIONs.
The IMPORTANT format indicates operational requirements and restrictions. To operate
the imagePRESS Server correctly and avoid damage to the imagePRESS Server or other
property, be sure to read the IMPORTANT items carefully.
