SERVICE PROCEDURES 92
FIGURE 33: imagePRESS Server HDDs
The HDDs are mounted inside a bracket.
If you are replacing a HDD with a new one, you will need:
• The appropriate system software and documentation for the imagePRESS Server that you
are servicing.
• A compatible version of the user software for the networked computers that will print to
the imagePRESS Server.
NOTE: Copier interface board
and internal cables are not shown.
HDD 2
HDD 1
HDDs
HDD bracket
