SERVICE PROCEDURES 94
7. Remove the screws that attach the HDDs to the HDD bracket (see Figure 35).
FIGURE 35: Removing/replacing the HDDs from the HDD bracket
8. Remove the HDDs from the HDD bracket and place them in antistatic bags.
Do not unscrew the screws on the HDD covers. Loosening these HDD screws breaks the seal
and voids the HDD warranty.
Do not touch the drives with magnetic objects (such as magnetic screwdrivers), and avoid
placing items such as credit cards and employee ID cards that are sensitive to magnets near the
HDDs.
Replacement HDDs are not shipped with pre-installed system software. After you install the
drive, you must install the appropriate system software.
HDD bracket
Screw (1 of 4)
HDD 1
HDD 2
