SERVICE PROCEDURES 57
TO REMOVE THE COPIER INTERFACE BOARD
1. Shut down and open the imagePRESS Server (see pages 49 and 51).
To remove the copier interface board, you must remove the left panel.
2. Make sure that the copier interface cable is removed from the imagePRESS Server back panel.
3. Remove the board mounting bracket screw that attaches the copier interface board to the
chassis.
4. Remove the copier interface board from motherboard connector J12.
Grasp the copier interface board at the front and back edges and gently pull the board straight
out of its motherboard connector.
5. Place the copier interface board in an antistatic bag.
TO REPLACE THE COPIER INTERFACE BOARD
1. Seat the copier interface board in connector J12 on the motherboard (the topmost
connector), and then secure it to the chassis with the board mounting bracket screw that you
removed earlier.
The copier interface board edge connector is keyed to fit in slot J12 only when properly
oriented.
2. Reassemble the imagePRESS Server and verify its functionality (see page 104).
