Canon imagePROGRAF iPF820 - Page 141

Handling rolls
Removing rolls from the Roll 2 (Lower) position
1. Press the Load/Eject button.
2. Press ▲ or ▼ to select Remove Roll , and then press the OK button.
3. Press ▲ or ▼ to select Roll 2 (Lower) , and then press the OK button.
The roll can now be removed.
4. After conrming that the Online lamp is of f, hold the Roll Unit Lever (a) and pull out the Roll Unit .
5. Using both hands, rotate the Roll Holder in the direction of the arrow to rewind the roll.
6. Remove the Roll Holder from the Roll Holder Slot .
Note
• For instructions on removing the Roll Holder from rolls, see “Removing the Roll Holder from Rolls”.
(→P .129)
• T o load new paper in the printer at this point, see “Loading Rolls in the Printer”. (→P .1 18)
Handling Paper 127
