Handling rolls
Loading rolls in the Roll 2 (Lower) holder
Caution
• Do not detach the Roll Unit in the following cases.
• During printing
V ibration from removing the Roll Unit may af fect the printing quality .
• If a sheet is loaded in the printer
The sheet may be ejected, and (rarely) it may be bent.
1. Conrm that a roll is selected as the paper source. ( → P .1 12)
2. Holding the Roll Unit Lever (a), pull out the Roll Unit .
3. Holding the Roll Holder so that the side with the white gear faces the side of the Roll Holder
Slot with a white gear , load the Roll Holder shaft (a) into the grooves (b) on both ends of the
Roll Holder Slot .
Caution
• Be careful not to drop the roll and hurt yourself when loading it.
• Be careful not to pinch your ngers between the Roll Holder shaft (a) and the guide grooves
(b) when loading rolls.
122 Handling Paper
To Next Page
