Printing CAD Drawings
Fine-T uning Monochrome Settings When Printing Line
Drawings (W indows)
Y ou can specify your own print settings instead of using the Print T arget presets. This topic describes how to
ne-tune monochrome settings before printing.
1. Choose Print in the application menu.
2. Select the printer in the dialog box, and then display the printer driver dialog box. ( → P .381)
3. Make sure the Main sheet is displayed.
4. In the A Media T ype list, select the type of paper that is loaded.
5. Click D Advanced Settings to switch the print mode.
6. Click Monochrome in the G Color Mode list.
Note
• Monochrome (BK ink) may not be available for all types of paper .
182 W orking With V arious Print Jobs
