Handling rolls
Attaching the Roll Holder to Rolls
When printing on rolls, attach the Roll Holder to the roll.
Rolls have a two- or three-inch paper core. Use the correct attachment for the paper core. The printer comes
equipped with the 2-Inch Paper Core Attachment installed.
Using the 2-Inch Paper Core Attachment Using the 3-Inch Paper Core Attachment
Roll Holder Side Holder Stopper Side Roll Holder Side Holder Stopper Side
No Attachment Needed 2-Inch Paper Core
Attachment
3-Inch Paper Core
Attachment #1
3-Inch Paper Core
Attachment #2
Important
• Be sure to use the correct attachment for the size of the roll paper core. The roll edge may be damaged
if you print when using an attachment that does not match, or if you print without using an attachment.
• Set the roll on a table or other at surface so that it does not roll or fall. Rolls are heavy , and dropping a
roll may cause injury .
• Cut the edge of the roll paper if it is uneven, dirty , or has tape residue.
Uneven, dirty , or sticky edges may cause feeding problems and af fect the printing quality .
Be careful not to cut through any barcodes printed on the roll.
• Align the edges of the paper on both ends of the roll.
• For details on supported sizes and types of rolls, see “Paper Sizes” or the Paper Reference Guide .
( → P .109) ( → P .104)
• After pressing the Load/Eject button, you can refer to instructions on the Display Screen as you load
the paper .
Handling Paper 1 15
