Optional accessories
Optional accessories
Roll Holder Set
Load a roll on the roll holder and then load the holder in the printer . The Roll Holder in the Roll Holder Set RH2-44 is
for use with both 2-inch and 3-inch paper cores. Use the correct attachment for the particular paper core. ( → P .1 15)
• Roll Holder Set RH2-44
• Roll Holder (for 2- and 3-inch paper cores)
• Attachments
Using the 2-Inch Paper
Core Attachment
Using the 3-Inch Paper Core Attachment
2-Inch Paper Core Attachment 3-Inch Paper Core Attachment
#1
3-Inch Paper Core Attachment
#2
IEEE 1394 (FireW ire) Expansion Board
An interface board to add an IEEE 1394 (also called "FireWire") port.
• IEEE1394 Expansion Board EB-05
Caution
• Note that EB-04 is incompatible.
For instructions on installing the IEEE 1394 expansion board, refer to the documentation provided with the
optional IEEE 1394 expansion board.
78 Printer Parts
