Adjusting the Printhead
8. Examine test pattern D-1 for printhead adjustment and determine the number of the pattern
with straight lines.
Note
• If lines seem straightest in two patterns but you cannot decide which one is better , choose an
intermediate value. For example, choose 1 1 if you cannot decide whether pattern 10 or 12 is better .
9. Press ▲ or ▼ to select the pattern number , and then press the OK button.
10. Repeat steps 7 and 9 to specify the adjustment value for D-2 to D-5 and D-7 to D-1 1 .
1 1. Press the ◄ button.
12. Press ▲ or ▼ to select Register Setting , and then press the ► button.
13. Press ▲ or ▼ to select Y es , and then press the OK button.
The adjustment value is now registered, and adjustment is complete.
Adjustments for Better Print Quality 547
