Problems with the printing quality
5. Refer to the following table to conrm the number on the Platen that corresponds to the size
of paper for printing.
Number
Paper Size
Dimensions
2 10"x12" / 8"x10" 254 mm (10 in.)
3 14"x17" 355 mm (14 in.)
4 17-in. Roll (431.8mm) / ANSI C 432 mm (17 in.)
5 JIS B2 / JIS B3 515 mm (20 in.)
6 ISO A1 / ISO A2 / 20"x24" 594 mm (23 in.) / 610 mm (24 in.)
7 ISO A0 / ISO A1 841 mm (33 in.)
8 36"x48" (ARCH E) / 24"x36" (ARCH D) 914 mm (36 in.)
9 JIS B0 / JIS B1 1030 mm (40.5 in.)
10 Poster 42"x60" 1,067 mm (42 in.)
6. Using the back of the Cleaning Brush , move the Switch to the side opposite ●, corresponding to
the size of the paper for printing.
In this case, note that you will move the switch in the opposite direction from the direction in
step 4.
7. Close the T op Cover .
630 T roubleshooting
To Next Page
