Chapter 3
3-6
(12) Pull up the Printhead Fixer Cover to open it completely.
F-3-15
(13) Holding the Printhead by the grips [1], remove it from the case.
F-3-16
- When handling the Printhead, always hold it by the grips [1].
- Never touch the printhead nozzles [2] or the metal contacts [3]. The printhead can damage or a printing failure can occur. Do not reattach the removed protective
caps.
- Dispose of these parts following the local regulation.
F-3-17
(14) Remove the orange Safety Cap 1 [1]. While squeezing the grips of Safety Cap 2 [2], pull the cap down to remove it.
F-3-18
- Never touch the ink supply section [4].
This may cause printing problems.
- The Printhead is filled with ink. When removing Safety Cap 1 [1] and Satety Cap 2 [2], be careful not to spill it.
- Do not reattach the protective material after removing it. Dispose of these materials according to local regulations.
[1]
[1]
[1]
[2]
[3]
[4]
[1]
[2]
[3]
