5 CUTTER_OUTB OUT Cutter motor driver signal B
6 SNS_3V_1 OUT Power supply (+3.3V)
7 GND - GND
8 HAKUSHA_CAM_SNS_R IN Spur cam sensor output signal
9 HAKUSHA_MOTOR_AM OUT Spur motor drive signal AM
10 HAKUSHA_MOTOR_AP OUT Spur motor drive signal AP
11 FAN_VM OUT Power supply (+26V)
12 MIST_FAN_LOCK IN Mist fan lock signal
13 MIST_FAN_PWM OUT Mist fan duty control signal
14 GND - GND
J2512 (Suction fan, Maintenance cartridge relay PCB, Paper detection sensor, Lift cam sensor)
Pin Number Signal name IN/OUT Function
1 FAN_VM OUT Power supply (+26V)
2 PLATEN_FAN_LOCK IN Suction fan lock signal
3 PLATEN_FAN_PWM OUT Suction fan duty control signal
4GND - GND
5 MENT_SDA IN/OUT Maintenance cartridge rom control signal (data)
6 MENT_SCL IN/OUT Maintenance cartridge rom control signal (clock)
7GND - GND
8 MENT_3V Power supply (+3.3V)
9 SNS_3V_1 OUT Power supply (+3.3V)
10 N.C. - N.C.
11 N.C. - N.C.
12 N.C. - N.C.
13 GND - GND
14 PE_SNS IN Paper ditection sensor output signal
15 SNS_3V_1 OUT Power supply (+3.3V)
16 GND - GND
17 LIFT_CAM_SNS IN Lift cam sensor output signal
J2601 (Operation panel)
Pin Number Signal name IN/OUT Function
1 POWER_ON IN Power switch signal
2 PM_START OUT Power supply (+5V)
3 BUZZER OUT Buzzer control signal
4 PDODATA OUT Panel IC control signal
5 +3.3V OUT Power supply (+3.3V)
6 PDI_DATA IN Panel IC data signal
7 GND - GND
8 /PANEL RESET OUT Panel reset signal
9 GND - GND
10 PDOPCLK OUT Panel IC clock signal
11 SNS_5V OUT Power supply (+5V)
12 /PDOCS_L OUT Panel supply chip select signal
J2703 (Auto feed roll unit)
Pin Number Signal name IN/OUT Function
1 OPT_5V OUT Power supply (+5V)
2GND - GND
3 ROLL_CAM_SNS IN Roll cam sensor signal
4 ROLL_PAPER_SNS IN Roll media sensor signal
5 ROLL_UNIT IN Roll unit detection signal
6 VM OUT Power supply (+26V)
7 VM OUT Power supply (+26V)
8 /ROLL_SLEEP OUT Roll motor driver sleep signal
J2511 (Spur motor, Spur cam sensor, Mist fan, Cutter motor, Cutter right detection sensor)
Pin Number Signal name IN/OUT Function
