Canon iPF6100 - Page 494

Chapter 6
6-70
T-6-116
45 GND - GND
46 H0-D-DATA-7-OD IN Odd head R data signal 7(D)
47 GND - GND
48 H-DASH LICC2 B IN Analogue switch A/D trigger signal
49 GND - GND
50 GND - GND
J13 (Connect to Main controller PCB J3601)
Pin Number Signal name IN/OUT Function
1 GND - GND
2 H0-A-HE-0 IN Head R heat enable signal 8(E)
3 GND - GND
4 H0-A-DATA-0-EV IN Even head R data signal 0(A)
5 GND - GND
6 H0-A-HE-1 IN Head R heat enable signal 8(E)
7 GND - GND
8 H0-A-DATA-1-EV IN Even head R data signal 1(A)
9 GND - GND
10 H0-B-DATA-2-EV IN Even head R data signal 2(B)
11 GND - GND
12 H0-B-DATA-3-EV IN Even head R data signal 3(B)
13 GND - GND
14 H0-C-DATA-4-EV IN Even head R data signal 4(C)
15 GND - GND
16 H0-B-HE-3 IN Head R heat enable signal 8(E)
17 GND - GND
18 H0-C-DATA-5-EV IN Even head R data signal 5(C)
19 HEAD_3V IN Power supply (+3V)
20 HEAD_3V IN Power supply (+3V)
21 GND - GND
22 H0-LT IN Head R data latch signal
23 GND - GND
24 H0_CLK IN Head R data clock signal
25 GND - GND
26 GND - GND
27 LICSEL1 IN Head R analogue switch latch signal
28 LICSEL2 IN Head R analogue switch clock signal
29 LICSEL0 IN Head R analogue switch data signal
30 GND - GND
31 GND - GND
32 H0-DSOUT1 OUT Head R temperature output 1
33 GND - GND
34 H0-DSOUT2 OUT Head R temperature output 2
35 GND - GND
36 H0-C-DATA-5-OD IN Odd head R data signal 5(C)
37 GND - GND
38 H0-C-HE-5 IN Head R heat enable signal 5(C)
39 GND - GND
40 H0-D-HE-6 IN Head R heat enable signal 6(D)
41 GND - GND
42 H0-D-DATA-6-OD IN Odd head R data signal 6(D)
43 GND - GND
44 H0-D-DATA-6-EB IN Even head R data signal 6(D)
45 GND - GND
46 H0-D-DATA-7-EV IN Even head R data signal 7(D)
47 GND - GND
48 H0-D-HE-7 IN Head R heat enable signal 7(D)
49 GND - GND
50 H0-E-DATA-8 IN Even head R data signal 8(E)
J12 (Connect to Main controller PCB J3501)
Pin Number Signal name IN/OUT Function
