Chapter 6
6-71
T-6-117
J14 (Head R)
Pin Number Signal name IN/OUT Function
1 VH OUT Power supply (+21.5V)
2 VH OUT Power supply (+21.5V)
3 VH OUT Power supply (+21.5V)
4 VHT OUT Head R Transistor drive Power supply
5 H0-F-DATA-10-EV OUT Even head R data signal 10(F)
6 EEPROM_SDA IN/OUT EEPROMcontrol signal (data)
7 EEPROM_SCL OUT EEPROMcontrol signal (clock)
8 HEAD_3V OUT Power supply (+3V)
9 H0-C-DIA1 IN Head R DI sensor signal 1(C)
10 H0-A-HE-1 OUT Head R heat enable signal 8(E)
11 VH OUT Power supply (+21.5V)
12 VH OUT Power supply (+21.5V)
13 VH OUT Power supply (+21.5V)
14 VH OUT Power supply (+21.5V)
15 VH OUT Power supply (+21.5V)
16 H0-E-DATA-9-OD OUT Odd head R data signal 9(E)
17 H0-F-HE-11 OUT Head R heat enable signal 11(F)
18 H0-E-DIA1 IN Head R DI sensor signal 1(E)
19 H0-D-DIA1 IN Head R DI sensor signal 1(D)
20 GND - GND
21 HEAD_3V OUT Power supply (+3V)
22 H0-B-DATA-3-EV OUT Even head R data signal 3(B)
23 H0-A-DATA-0-EV OUT Even head R data signal 0(A)
24 H0-B-HE-2 OUT Head R heat enable signal 2(B)
25 VH OUT Power supply (+21.5V)
26 VH OUT Power supply (+21.5V)
27 H0-D-DIA2 IN Head R DI sensor signal 2(D)
28 H0-E-HE-8 OUT Head R heat enable signal 8(E)
29 H0-E-DIA2 IN Head R DI sensor signal 2(E)
30 H0-F-DIA2 IN Head R DI sensor signal 2(F)
31 H0-E-HE-9 OUT Head R heat enable signal 9(E)
32 H0-D-DATA-7-EV OUT Even head R data signal 7(D)
33 H0-D-HE-6 OUT Head R heat enable signal 6(D)
34 H0-C-DATA-5-0D OUT Odd head R data signal 5(C)
35 H0-C-DATA-4-EV OUT Even head R data signal 4(C)
36 H0-A-DATA-1-EV OUT Even head R data signal 1(A)
37 H0-A-DIA2 IN Head R DI sensor signal 2(A)
38 H0-B-DIA2 IN Head R DI sensor signal 2(B)
39 H0-C-HE-4 OUT Head R heat enable signal 4(C)
40 H0-D-DATA-7-OD OUT Odd head R data signal 7(D)
41 H0-E-DATA-8-OD OUT Odd head R data signal 8(E)
42 H0-F-HE-10 OUT Head R heat enable signal 10(F)
43 H0-F-DATA-11-EV OUT Even head R data signal 11(F)
44 H0-F-DATA-8-EV OUT Even head R data signal 8(F)
45 H0-D-DATA-6-EV OUT Even head R data signal 6(D)
46 H0-C-DIA2 IN Head R DI sensor signal 2(C)
47 H0-C-DATA-5-EV OUT Even head R data signal 5(C)
48 H0-B-DIA1 IN Head R DI sensor signal 1(B)
49 H0-A-HE-0 OUT Head R heat enable signal 8(E)
50 H0-B-DATA-2-OD OUT Odd head R data signal 2(B)
51 H0-B-DATA-3-OD OUT Odd head R data signal 3(B)
52 H0-C-DATA-4-OD OUT Odd head R data signal 4(C)
53 GND - GND
54 GND - GND
55 GND - GND
56 H0-F-DATA-11-OD OUT Odd head R data signal 11(F)
57 H0-E-DATA-9-EV OUT Even head R data signal 9(E)
58 GND - GND
