Chapter 8
8-34
Printhead error.
Open top cover and replace
the right printhead.
03800400-2803 Printhead EEPROM error Replace printhead.
Right printhead error.
Open top cover and replace
the right printhead.
03800401-2803 Right printhead EEPROM error Replace the right printhead.
Left printhead error.
Open top cover and replace
the left printhead.
03800402-280B Left printhead EEPROM error Replace the left printhead.
PHead needs cleaning.
Press Online to clear error.
03800500-280C Printhead found to have many non-discharging
nozzles during a non-discharging inspection (printing
paused)
Clean the printhead.
Identify the nozzles in a nozzle check pattern.
Replace the printhead.
Execute printhead cleaning.
If this message is still
displayed, replace the
printhead.
03800500-280C Printhead found to have many non-discharging
nozzles during a non-discharging inspection (printing
paused)
Clean the printhead.
Identify the nozzles in a nozzle check pattern.
Replace the printhead.
Execute printhead cleaning.
If this message is still
displayed, replace the
printhead.
Printing stopped.
03800500-2827 Printhead found to have many non-discharging
nozzles during a non-discharging inspection (printing
stopped)
Clean the printhead. Identify the nozzles in a nozzle
check pattern.
Replace the printhead.
Hardware error.
03800500-2F2F
Turn off printer, wait, then
turn on again.
03800500-2F2F The non-discharge of the EVEN or ODD line (640-
nozzles) is detected the 320-nozzles or more.
Check the head management sensor and
surrounding parts.
Check that the printhead is attached correctly.
Replace the head management sensor.
Replace the printhead.
Hardware error.
03800500-2F30
Turn off printer, wait, then
turn on again.
03800500-2F30 Detectable area failure (when adjusting the position of
non-discharging nozzle)
The gap of detection position of nozzle both ends is
big.
Check the ink tube unit and surrounding parts.
Check the purge unit and surrounding parts.
Check the head management sensor and
surrounding parts.
Check the flexible cable unit and surrounding parts.
Check that the printhead is attached correctly.
Replace the main controller PCB.
Replace the printhead.
Replace the carriage unit.
Hardware error.
03800500-2F31
Turn off printer, wait, then
turn on again.
03800500-2F31 Non-discharge detection optical axis error Check the head management sensor.
Replace the head management sensor.
Replace the printhead.
Hardware error.
03800500-2F40
Turn off printer, wait, then
turn on again.
03800500-2F40 The non-discharge of all colors and chips (A/B,
EVEN/ODD) and nozzles is detected.
Check the ink tube unit and surrounding parts.
Check the purge unit and surrounding parts.
Check the head management sensor and
surrounding parts.
Check the flexible cable unit and surrounding parts.
Check that the printhead is attached correctly.
Replace the head management sensor.
Replace the main controller PCB.
Replace the printhead.
Replace the carriage unit.
Hardware error.
03800500-2F41
Turn off printer, wait, then
turn on again.
03800500-2F41 About all chips and nozzles of one color, the non-
discharge is detected.
Check the ink tube unit and surrounding parts.
Check the purge unit and surrounding parts.
Check the head management sensor and
surrounding parts.
Check the flexible cable unit and surrounding parts.
Check that the printhead is attached correctly.
Replace the main controller PCB.
Replace the printhead.
Replace the carriage unit.
Hardware error.
03800500-2F42
Turn off printer, wait, then
turn on again.
03800500-2F42 About single line (A or B) and all nozzles (1280-
nozzles) of one color, the non-discharge is detected.
Check the head management sensor and
surrounding parts.
Check the flexible cable unit and surrounding parts.
Check that the printhead is attached correctly.
Replace the main controller PCB.
Replace the printhead.
Replace the carriage unit.
Hardware error.
03800500-2F43
Turn off printer, wait, then
turn on again.
03800500-2F43 About single chip (A or B, EVEN or ODD) and all
nozzles (640-nozzles) of one color, the non-discharge
is detected.
Check the head management sensor and
surrounding parts.
Check the flexible cable unit and surrounding parts.
Check that the printhead is attached correctly.
Replace the main controller PCB.
Replace the printhead.
Replace the carriage unit.
Hardware error.
03800500-2F44
Turn off printer, wait, then
turn on again.
03800500-2F44 The non-discharge of the EVEN or ODD line (640-
nozzles) is detected.
Check the head management sensor and
surrounding parts.
Check that the printhead is attached correctly.
Replace the main controller PCB.
Replace the printhead.
Replace the carriage unit.
Hardware error.
03800500-2F47
Turn off printer, wait, then
turn on again.
03800500-2F47 Head management sensor failure
The APCCHK signal of head management sensor is
out of range.
Check the head management sensor and
surrounding parts.
Replace the head management sensor.
Replace the main controller PCB.
Clean right P Head 03800501-280D The number of right printhead nozzle was over level
that can back up non-discharging nozzle. (printing
paused)
Clean the printhead.
Change the setting of nozzle check warning.
Replace the right printhead.
Display massage Code* Condition detected Action
