7-MAINTENANCE

Cardanshafts-Greasing

3.Numberofgreasettings(1):2(4WD)/1(2WD)

NOTE:Onlylubricatetheshaft,theu-jointdoesnothave

agreasetting.

LEEN11T0391AA18

Greasespecications

UseCASEAKCELAMOLYGREASE(MAT3550)or

agreasewhichmeetsthefollowingstandard:

•

NLGI2

NOTE:TUTELAMULTI-PURPOSEEPGREASE251H,GR-9

canalsobeused.

7-61
