9-SPECIFICATIONS
Loaderattachmentperformance
580T/580STwithstraightloaderarms
RAIL15TLB0563FA4
Fronttires
12.5/80-18I3
Reartires18.4-26R4
Standardloaderbucket1m³(35.3ft³)
A
Maximumheight/dimensions4333mm(170.6in)
B
Maximumheightofloaderbucketpin/pivot3490mm(137.4in)
C
Maximumdumpingheight
2752mm(108.3in)
D
Diggingdepth
120mm(4.7in)
E
Loaderattachmentreachwhenraisedindumpingposition(accordingtofront
counterweight)
808mm(31.8in)
F
Angleofloweredclosedbucket
36°
G
Dumpingangle
45°
