9-SPECIFICATIONS
Loaderattachmentperformance
580T/580STwithbentloaderarmand590ST
LEEN11T0024FA5
Fronttires
12.5/80-18I3
Reartires18.4-26R4
Standardloaderbucket1m³(35.3ft³)
A
Maximumheight/dimensions4255mm(167.5in)
B
Maximumheightofloaderbucketpin/pivot3460mm(136.2in)
C
Maximumdumpingheight
2625mm(103.3in)
D
Diggingdepth
120mm(4.7in)
E
Loaderattachmentreachwhenraisedindumpingposition(accordingtofront
counterweight)
830mm(32.7in)
F
Angleofloweredclosedbucket
45°
G
Dumpingangle
45°
