Case 695ST - Page 409

To Next Page

To Previous Page

9-SPECIFICATIONS

695ST

LEEN11T0026FA6

Fronttires

440/80R28IT530

Standardloaderbucket1.15m³(40.6ft³)

Maximumheight/dimensions4350mm(171.3in)

Maximumheightofloaderbucketpin/pivot3490mm(137.4in)

Maximumdumpingheight

2715mm(106.9in)

Diggingdepth

113mm(4.4in)

Loaderattachmentreachwhenraisedindumpingposition(accordingtofront

counterweight)

745mm(29.3in)

Angleofloweredclosedbucket

45°

Dumpingangle

45°

9-19
