9-SPECIFICATIONS
Backhoeattachmentperformance
580T/580STwithanoverlappingcylinderboomand590ST
LEEN11T0034FA11
Fronttires
12.5/80–1813
Reartires18.4–26R4
Standardloaderbucket314mm(12.4in)
Standard/
retracteddipper
Telescopicdipper
extended
A
Maximumdiggingheight
5875mm
(231.3in)
6790mm
(267.3in)
B
Maximumheightatfullload
3925mm
(154.5in)
4835mm
(190.4in)
C
Maximumdiggingdepth
4370mm
(172.0in)
5435mm
(214.0in)
D
Maximumdiggingreachwithloweredbucket
5230mm
(205.9in)
6240mm
(245.7in)
EMaximumreachwhenloaded
870mm(34.3in)1425mm(56.1in)
F
Bucketdiggingangle
200°195°
9-24
