Case 695ST - Page 415

9-SPECIFICATIONS
695STsideshift
LEEN11T0035FA12
Frontandreartires
440/80R28IT530
Reartires
914mm(36.0in)
Standard/
retracteddipper
Telescopicdipper
extended
A
Maximumdiggingheight
6190mm
(243.7in)
7215mm
(284.1in)
B
Maximumheightatfullload
4250mm
(167.3in)
5270mm
(207.5in)
C
Maximumdiggingdepth
4595mm
(180.9in)
5810mm
(228.7in)
D
Maximumdiggingreachwithloweredbucket
5185mm
(204.1in)
6645mm
(261.6in)
EMaximumreachwhenloaded
1065mm(41.9in)1735mm(68.3in)
F
Bucketdiggingangle
198°195°
9-25
