2-SAFETYINFORMATION

Emergencystop

MOLI12LBB0076AA8

Raiseloadorbucket

MOLI12LBB0077AA9

Lowerloadorbucket

MOLI12LBB0078AA10

Raiseloadorbucketslowly

MOLI12LBB0079AA11

2-21
