2-SAFETYINFORMATION

Lowerloadorbucketslowly

MOLI12LBB0080AA12

Turnmachineleft

MOLI12LBB0081AA13

Turnmachineright

MOLI12LBB0082AA14

Rollbackloaderbucket

MOLI12LBB0083AA15

2-22
