3-CONTROLSANDINSTRUMENTS

Overheadcontrols

Roofcurtain

Toopentheroofcurtain,slideittowardtherearusingthe

handles.Toclosethecurtainslideittowardthefront.

VHIVJ6-001A1

Roofhatch

Toopentheroofhatch,operatethehandleandpushthe

handle.

Toclosetheroofhatch,pullthehandleuntilengagement.

NOTICE:Sinceroofhatchopeningisassistedbytwogas

struts,simplyfollowthroughtheclosingmovementwith-

outpullingortryingtoholditback.

D178LS-001A1

Sunshield(optional)

Thesunshieldisxedtothewindshieldandcaneasilybe

positionedasrequired.

R566HK-001A1

3-59
